CDD FantasY IV

Made In USA
Download Instructions Download Spec Sheet

CDD Fantasy IV

Aluminum 5/8" Mitered Frame Door

Here is the crowning jewel of framed wardrobe doors! Fantasy IV® features a stylish, super-strong commercial grade aluminum frame in choice of six fashion-conscious Anodized colors with color-coordinated vinyl glazing. It’s incredible, luxuriously thick 6mm plate mirror is reinforced with our standard Polylam safety backing and then backed with our exclusive Aromatic Cedar Backing for the ultimate in wardrobe haute couture. Enjoy all the benefits of a fine cedar closet in a top-quality sliding mirrored wardrobe door! Ultraglide 2-1/4" deep felt-lined top channel and jump-proof bottom track as well as precision 1-1/2 dual race ball bearing wheels are standard. Elegant 1" beveling on all sides and 1/2" beveled mirror fascia are optional. Triple ultraglide top channel and bottom track are also available on Fantasy IV®.

Special Features

All Aluminum Closet Door System
1) Heavy gauge #6063 aluminum Extrusions
2) Mitered corners
3) Cat II Laminated Safety Backing Copper-Free Mirror 6mm thick
4) Top Channel and Bottom Track are extruded aluminum finished to match Panels
5) 1-1/2" diameter Wheels with steel Races and 5/32" Ball Bearings in extra-heavy 18-gauge steel Housing
6) Bottom rolled with jump-proof Tracks
7) Available with Painted White Glass, Chalkboard, Dry Erase Board and Woodgrain Designs

Brushed Nickel
Satin Clear / Silver
Bright Clear / Silver
Satin Gold
Bright Gold
Bronze
•
•
  • Finished Opening
    Width x Height
  • 48 X 81
  • 60 X 81
  • 72 X 81
  • 84 X 81
  • 96 X 81
  • 108 X 81
  • 120 X 81
  • 108 X 81
  • 120 X 81
  • 144 X 81
  • 168 X 81
  • 192 X 81
  • Number of Panels
    Width X Height
  • 2 @ 24 5/8 X 78 5/8
  • 2 @ 30 5/8 X 78 5/8
  • 2 @ 36 5/8 X 78 5/8
  • 2 @ 42 5/8 X 78 5/8
  • 2 @ 48 5/8 X 78 5/8
  • 2 @ 54 5/8 X 78 5/8
  • 2 @ 60 5/8 X 78 5/8
  • 3 @ 36 5/8 X 78 5/8
  • 3 @ 40 5/8 X 78 5/8
  • 3 @ 48 5/8 X 78 5/8
  • 4 @ 42 5/8 X 78 5/8
  • 4 @ 48 5/8 X 78 5/8
  • Finished Opening
    Width x Height
  • 48 X 96
  • 60 X 96
  • 72 X 96
  • 84 X 96
  • 96 X 96
  • 108 X 96
  • 120 X 96
  • 108 X 96
  • 120 X 96
  • 144 X 96
  • 168 X 96
  • 192 X 96
  • Number of Panels
    Width X Height
  • 2 @ 24 5/8 X 93 5/8
  • 2 @ 30 5/8 X 93 5/8
  • 2 @ 36 5/8 X 93 5/8
  • 2 @ 42 5/8 X 93 5/8
  • 2 @ 48 5/8 X 93 5/8
  • 2 @54 5/8 X 93 5/8
  • 2 @ 60 5/8 X 93 5/8
  • 3 @ 36 5/8 X 93 5/8
  • 3 @ 40 5/8 X 93 5/8
  • 3 @ 48 5/8 X 93 5/8
  • 4 @ 42 5/8 X 93 5/8
  • 4 @ 48 5/8 X 93 5/8
•
•
•



Painted White Glass
